Qunfeng Garbage Dump TruckRefuse Transfer Station
Products Introduction
LJYS100-CZ vertical compression of refuse transfer station is one set of special equipment for environmental sanitation which specifics to mass household trash.It is adopted our large advanced technique of refuse compression. This equipment is featuring high efficiency of compression, strong environmental adaptation, high reliability and durability. Combining with the developed matched self-discharging refuse transfer vehicle. It will mainly meet the need of refuse processing in small-medium cities and large towns.
Functions:
- LJYS100-CZ vertical compression of refuse transfer station works with high efficiency,also its compression rate is high and cycle time is short.
- With high structural strength and advanced anti corrosive process. The machine produced by high-quality and high-strength steel, and its overall structure is stronger than other models in the market.The machine is adopted advanced anti-corrosion technology, which can effectively extend its lifespan.
- 垃圾桶的提升高度可以根据具有不同配置的运输车辆灵活地调节。
- 采用自动快进，压缩和压缩维护功能。垃圾压缩过程：首先，压力向下快速向下，直到压力头的底表面压缩垃圾，然后减慢压缩速度。垃圾被压缩后，自动压缩维护功能可以确保垃圾最好的密度。
- 自动对准功能可以避免手动操作事故。当需要抬起垃圾桶时，压头的悬挂箱滑动销可以自动找到盒子上的提升座位并停止等待悬挂盒提升。
- Machine’s middle door and front door have good synchronization. Cylinder on both sides of the two doors adopt high strength gear racks which enable machine to run smoothly.
- Microcomputer control system adopts advanced PLC control technology, the garbage compression cycle can realize full automatic operation, also automatic and manual operation can be switched flexibly, which greatly improve the reliability of equipment.
- The hydraulic system has high reliability. Machine adopts independent integrated hydraulic station and its main components of hydraulic system use international branded products.
技术数据 |
LJYS100-CZ |
尺寸：长度×宽×高度（mm） |
5720×3350×6600 |
Rated daily capacity(t) |
100. |
Max.daily capacity(t) |
120 |
Capacity of compression bin (m³) |
5 |
垃圾块的尺寸（mm） |
1850×1600×≤1450 |
Weight of garbage block(t) |
4×2=8 |
Rated working pressure(Mpa) |
21 |
Power(kW) |
30 |
The height of garbage bin can be adjusted according to different transport vehicles which are configured to the transfer station.
Machine is produced by high strength steel and adopts advanced anti-corrosion technology, which can effectively extend its lifespan.
采用先进的PLC控制技术，垃圾压缩周期
可以实现自动操作，还可以自动和手动操作
can be switched.
Qunfeng Machinery.
Global service system
As a model enterprise of China building material machinery, Qunfeng provides upscale and high-quality machinery with intelligent technology for their customers. Covering six continents with 7 overseas service stations and 24 domestic offices, Qunfeng has served 8000 clients from 110 countries and regions with more efficient intelligent manufacturing equipment. Qunfeng has earned great reputation in the world with its products being exported to high-level market worldwide, include Asia, Europe, South America, Oceania, Africa and North America.
